Orion-Tr Smart DC-DC charger 12/12-30A (360W)
Description
Orion-Tr Smart DC-DC Charging Converter - Compatible with intelligent alternators
The Victron DC-DC charging converter Orion-Tr Smart for charging the living area battery while driving is compatible with so-called intelligent alternators in Euro 6, Euro 5+ and Euro 5 vehicles in 12V systems. Charging converters that charge the on-board batteries via the alternator are often referred to as B2B chargers or charging boosters.
Configuration options and monitoring via Bluetooth.
Suitable for lithium and lead batteries (AGM, gel, lead-acid, LiFePO4).
To increase the output power, several devices can be connected in parallel.
Suitable for high temperatures up to 55 ° C with a full rated output up to 40 ° C.
Optimized and monitored charging
The three-stage charging algorithm (constant current - constant voltage - float charge voltage) in the Orion Tr-Smart DC-DC charging converter ensures a long battery life and optimal performance through adapted charging of the battery.
Monitored charging is also important, especially in vehicles with lithium systems, in order to protect the alternator itself from overload.
Customizable charging algorithms
The charging characteristic can be programmed and adjusted exactly to the needs of the type of battery used. The device has eight pre-programmed battery settings for this purpose.
Configuration and control
Several parameters can be configured via Bluetooth on Apple and Android smartphones, tablets or other devices and individually adjusted in the VictronConnect app.
Engine running detection
Intelligent alternators in Euro 5, 5+, Euro 6 vehicles are switched off to save fuel when the starter battery is fully charged. The engine running detection integrated in the Orion-Tr Smart DC-DC charging converter registers that the alternator has not been switched off due to a stationary engine in order to prevent the starter battery from discharging. There is no need for any further wiring or installation.
Battery disconnection
If the engine does not run, the starter and living area battery are automatically separated from each other.
Input voltage lock
Switches off when the input voltage falls below the blocking value. When the input voltage rises again, the charging converter is automatically reactivated. This value can also be set with the Victron app.
Remote on / off switching
The charging converter can be activated and deactivated via the VictronConnect app or a hardwired remote on / off switch or the battery management system (BMS).
Safe operation
The Orion-Tr Smart charging converter has overheating protection and load reduction at high temperatures. It is also overload and short-circuit protected and the connector also has overtemperature protection.
Technical specifications
Input voltage range: 10-17 V
Undervoltage shutdown: 7 V
Undervoltage restart: 7.5 V
Nominal output voltage: 12.2 V
Output voltage setting range: 10-15 V
Output voltage tolerance: +/- 0.2 V
Output noise: 2 mV rmsCont.
Output current at nominal output voltage and 40 ° C: 30 A
Maximum output current (10 s) at nominal output voltage minus 20%: 40 A
Short-circuit output current: 60 ACont.
Output power at 25 ° C: 430 WCont. Output power at 40 ° C: 360 W
Efficiency: 87%
No load input load current: <80 mA
Idle current: <1 mA
Operating temperature range -20 to + 55 ° C (reduction in performance by 3% per ° C above 40 ° C)
Air humidity Max. 95%, non-condensing
Direct current connection screw terminals
Maximum cable cross-section 16 mm² (AWG6)
weight : 1.8 kg
Dimensions HxWxD: 130 x 186 x 70 mm (5.1 x 7.3 x 4.0 ″)
