MC4 Surface-Mounted Plug for Solar Stranded Wire 2.5 mm²

MC4 panel-receptacle connectors are the interface between an inverter or junction box or junction and a branch cable.

Mounting directly by means of screw thread or in perforated plate with plastic nut (included in delivery).

Suitable socket see item 38288.

  • Currently out of stock
4,95 €
incl. 19% VAT , plus shipping costs (Paket)
From Unit price / pcs
5 4,70 €*
20 4,46 €*
  • travel-experienced employees
  • shipping with DHL & GLS
  • everything from one source
  • payment by Paypal or bank transfer
Description

MC4 PV Surface-Mounted Plug

Quick and clean mating. The degree of protection (IP65 and IP68) ensures high sealing performance. Supplied with pre-assembled flat seal.

For use with suitable connectors from the MC4 connector family and appropriate cables.


Technical Data

  • Ambient temperature range: -40 °C...+85 °C (TÜV/UL)
  • Upper limit temperature: 105 °C
  • Degree of protection, mated: IP65/IP68 (1 m, 1 h)
  • Degree of protection, unmated: IP2X
  • Pollution degree: 3
  • Max. contact resistance of connector: < 0.25 mΩ
  • Rated impulse voltage: 16 kV
  • Contact system: MULTILAM
  • Connection type: Crimping
  • Contact material: Copper, tinned
  • Insulation material: PC/PA
  • Locking system: Locking type
  • Flammability class: UL94:V-0
  • TÜV Rheinland certificate number: R 60127181
  • UL certificate number: E343181





manufacturer information:
HELU KABEL GmbH
Schloßhaldenstr. 10
Hemmingen, 71282
Baden-Würtemberg, DE
info@helukabel.de

responsible person:
HELU KABEL GmbH
Schloßhaldenstr. 10
Hemmingen, 71282
Baden-Würtemberg, DE
info@helukabel.de

Technical specifications
Item weight:
 0,01 kg
