Cyrix-ct 12/24V-230A intelligent battery combiner, Victron Energy

Victron Energy Cyrix-ct 12/24V-230A is an intelligent coupling relay for the direct electrical connection of two battery banks (starter circuit and auxiliary circuit) for automatic charging of the consumer battery as soon as the starter battery is charged. Suitable for vehicles with 12V and 24V on-board voltage.

  • Available immediately
  • Delivery time: 3 - 4 Workdays (Other countries)
141,96 €
incl. 19% VAT , Free shipping to DE. shipping costs (Paket)
Old price: 152,95 €

  • travel-experienced employees
  • shipping with DHL & GLS
  • everything from one source
  • payment by Paypal or bank transfer

Victron Energy Cyrix-ct 12/24V-230A

The Cyrix battery coupler is a high performance microprocessor controlled relay that automatically connects batteries in parallel when one of them has reached a predetermined voltage value (indicating that the battery is being charged). It is therefore used to directly electrically connect two battery banks (starter circuit and build circuit).

It separates the batteries again when the voltage drops below the float voltage value (indicating that one or both batteries are being discharged).

Cyrix battery couplers are ideal for replacing isolating diodes. Their main feature is that there is practically no voltage loss, so that the output voltage of the alternators or battery chargers does not have to be increased.

Suitable for 12V and 24V battery banks, with automatic system voltage detection


  • Pass-through current: 230A (5 sec. 500A)
  • Switching-on voltage: 13V*-13.8V (26V-27.6V) (*with switch-on delay)
  • Switching-off voltage: 11V*-12.8V (22V-25.7V) (*with switch-off delay)
  • Manual control input "Start Assist" input pulse closes the relay for 30 sec.
  • Includes control connection cable
  • Dimensions LxWxD: 100x65x50mm
  • Connection thread: M8

Charging current limitation and charging parameter adjustments for lithium batteries do not occur, other or additional components are required for this, please contact us in this case
